Pneumatic high-temperature butterfly valve

Miss Shao : +86-1862762655

TEL: +86-513-88400999 FAX: +86-513-88400998 E-mail: jszk@vip.163.com



Pneumatic high-temperature butterfly valve (Zm/s A/cW-0.1Gk/b) is matched with pneumatic film and piston actuator. Change the flow of high temperature media in pipeline according to different control signals in the manufacture process of metallurgy, chemical industry and generating plant to automaticallycontrol and remotely control the manufacture process.
Ⅱ、 Main technical parameter

Work temperature()
-45~750
Material
Valve plate of valve body
0Cr25Ni20
Nominal pressure(MPa)
0.1
Shaft
0Cr25Ni20
Rotated angle of valve plate
0~70
Inside lining
High temperature concrete
Pressure of air source
0.5
Filling material
Soft graphite
Leakagerate
2.5%
Flow character
Approximate percentage


Main technical parameter of type ZSCW-0.1Gk/b

Ⅲ、 Outline and installation dimension
Outline see figure 1,Outline Installation dimension see table 4.
